Android tutorial -Custom dialog fragment

/**
Would you like to visit my new apps in google play :
"Best Motivational Stories"

https://play.google.com/store/apps/details?id=com.thanhcs.motivationstories

**/

Do you wanna create Android dialog like this :

Follow my android code below and you'll make that dialog :

CustomDialogFragment.java

package jp.classmethod.android.sample.customdialog;

import android.app.Dialog;

import android.graphics.Color;

import android.graphics.drawable.ColorDrawable;

import android.os.Bundle;

import android.support.v4.app.DialogFragment;

import android.view.View;

import android.view.View.OnClickListener;

import android.view.Window;

import android.view.WindowManager;

public class CustomDialogFragment extends DialogFragment {

    @Override

    public Dialog onCreateDialog(Bundle savedInstanceState) {

        Dialog dialog = new Dialog(getActivity());

        dialog.getWindow().requestFeature(Window.FEATURE_NO_TITLE);

        dialog.getWindow().setFlags(WindowManager.LayoutParams.FLAG_FULLSCREEN, WindowManager.LayoutParams.FLAG_LAYOUT_IN_SCREEN);

        dialog.setContentView(R.layout.dialog_custom);

        dialog.getWindow().setBackgroundDrawable(new ColorDrawable(Color.TRANSPARENT));

        // OK

        dialog.findViewById(R.id.positive_button).setOnClickListener(new OnClickListener() {

            @Override

            public void onClick(View v) {

                dismiss();

}

});

        // Close

        dialog.findViewById(R.id.close_button).setOnClickListener(new OnClickListener() {

            @Override

            public void onClick(View v) {

                dismiss();

}

});

        return dialog;

}

}

dialog_custom.xml

<?xml version="1.0" encoding="utf-8"?>

<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"

    android:layout_width="match_parent"

    android:layout_height="match_parent" >

    <LinearLayout

        android:layout_width="match_parent"

        android:layout_height="wrap_content"

        android:layout_alignParentTop="true"

        android:layout_below="@+id/title"

        android:layout_marginTop="6dp"

        android:layout_marginLeft="6dp"

        android:layout_marginRight="6dp"

        android:paddingBottom="20dp"

        android:background="@drawable/bg_dialog"

        android:gravity="center_horizontal"

        android:orientation="vertical"

>

        <TextView

            android:id="@+id/title"

            android:layout_width="match_parent"

            android:layout_height="wrap_content"

            android:background="@drawable/bg_dialog_title"

            android:padding="10dp"

            android:text="Title"

            android:textSize="18sp"

            android:textColor="@android:color/white"

/>

        <TextView

            android:id="@+id/message"

            android:layout_width="wrap_content"

            android:layout_height="wrap_content"

            android:layout_margin="20dp"

            android:lineSpacingExtra="6dp"

            android:text="MessageMessageMessageMessageMessageMessageMessageMessageMessage"

            android:textSize="16sp"

            android:textColor="#333333"

/>

        <!-- OK

        <Button

            android:id="@+id/positive_button"

            android:layout_width="wrap_content"

            android:layout_height="wrap_content"

            android:layout_marginTop="6dp"

            android:background="@drawable/bt_dialog_positive"

            android:text="OK"

            android:textColor="@android:color/white"

/>

    </LinearLayout>

    <!-- Close

    <Button

        android:id="@+id/close_button"

        android:layout_width="40dp"

        android:layout_height="40dp"

        android:layout_alignParentRight="true"

        android:layout_alignParentTop="true"

        android:background="@drawable/bt_dialog_close"

        android:text="×"

        android:textColor="#9acd32"

/>

</RelativeLayout>

bg_dialog.xml

<?xml version="1.0" encoding="utf-8"?>

<shape xmlns:android="http://schemas.android.com/apk/res/android" >

    <corners android:radius="5dp"/>

    <stroke android:width="2dp" android:color="#9acd32"/>

    <gradient android:startColor="#ffffff" android:endColor="#dcdcdc" android:angle="90"/>

</shape>

bg_title.xml

<?xml version="1.0" encoding="utf-8"?>

<shape xmlns:android="http://schemas.android.com/apk/res/android" >

    <corners android:topLeftRadius="5dp" android:topRightRadius="5dp"/>

    <solid android:color="#9acd32"/>

 </shape>

bt_dialog_positive.xml

<?xml version="1.0" encoding="utf-8"?>

<shape xmlns:android="http://schemas.android.com/apk/res/android" >

    <corners android:radius="5dp" />

    <solid android:color="#9acd32" />

 </shape>

bt_dialog_close.xml

<?xml version="1.0" encoding="utf-8"?>

<shape xmlns:android="http://schemas.android.com/apk/res/android"

    android:shape="oval">

    <solid android:color="@android:color/white"/>

    <stroke

        android:width="3dp"

        android:color="#9acd32"

/>

     </shape>

----------------------------DONE------------------------
